Backpack Volpi Cordless Pump V.Black Vita 16L

Battery-powered backpack pump Volpi V.Black Vita 16 liters

V.Black Vita 16 is the new 16-liter electric backpack pump with Original Volpi lithium battery, useful for dispensing plant protection products or other products that require fine nebulization. The Vita 16L battery-powered backpack pump is equipped with a comfortable padded backrest and two comfortable padded and adjustable shoulder straps, which make it easily transportable and comfortable during use and is ideal for pest control and gardening also thanks to a polypropylene tank    16  L and NBR gaskets.  The backpack is equipped with a reverse function and allows use both on the right and on the left (ambidextrous). The 2.0 Ah 14.4 volt battery allows the Volpi Vita 16 backpack pump to deliver up to 95 litres of water at a pressure of 2 bar (75 to 5 bar) before needing to recharge. Volpi V.Black Vita 16 is also equipped with a telescopic lance made of aluminium and brass, Adjustable brass nozzle, handle with ergonomic click lever with immediate stop, screw cap with lance holder and has a compartment with a cover for the rechargeable and replaceable lithium battery. Discover also the practical trolley included with weeding bar, to carry out weeding or irrigation operations more easily.

V.Black Vita 16 features:

• Tank capacity : 16 L
• Litres that can be dispensed per battery charge: with pressure 2 bar - up to 95 l / pressure 5 bar - up to 75 l
• V.Battery rechargeable and interchangeable lithium battery 14.4V - 2.0Ah - 28.8W
• Adjustable working pressure 0.5 ÷ 5 Bar - 7.25 ÷ 72.5 psi
• Telescopic lance in brass and aluminum
• High-performance diaphragm pump
• Min./max. temperature 5°C / 40°C
• Delivery hose length 1.2 m
• Filling mouth diameter 105 mm
• Empty weight of the pump with battery 3.2 kg

Technical specifications of the V.black VITA Volpi Pump

Details of the Volpi Waist Backpack Pump

Aluminium  lance
B  Handle with ergonomic Click lever with immediate stop
C  Electronic board with voltage control that keeps the pressure constant for the entire life of the battery
D  Adjustable brass nozzle
And  Screw cap with lance holder
F  Padded and adjustable shoulder straps
G  Polypropylene tank
H  Compartment with cover for rechargeable and replaceable lithium battery

Exploded view of spare parts Backpack Volpi battery-powered pump V.Black Vita

Spare parts for V.Black Vita backpack Volpi battery-powered pump (available to order - 23VBE12 = 12 litre model - 23VBE16 = 16 litre model):

1 CP0014S TANK 12L -  23VBE12
1A CP0015S TANK 16L - 23VBE16
2 CP0017 PUMP BASE 12L  - 23VBE12
2A CP0018 PUMP BASE 16L  - 23VBE16
3 23VBEK4 BATTERY DOOR-KNOB-CONTACTS-BOARD  LOCK KIT
4 23VBEK19 SCREW CAP WITH VALVE
5 23VBEK5 GRADUATED DOSING KIT-SIEVE-TANK FILTER /
6 22EPM5B DIAPHRAGM PUMP WITH PRESSURE SWITCH
7 23VBEK6 SUCTION-DELIVERY HOSE KIT + CLAMPS
8 WBLITA20 LI-ION BATTERY 14.4V- 2Ah
9 WSCH04 BATTERY CHARGE CONTROL BOARD
10 23VBEK7 DELIVERY HOSE KIT
11 163K GRIP
12 192/1MBR PROL. AL. D.10 CM.50   - 23VBE12
12A 189T TELESCOPIC EXTENSION WITH FITTING -  23VBE16
13 928 ADJUSTABLE BRASS NOZZLE
14 TES012 PAIR OF ADJUSTABLE SHOULDER STRAPS FOR 23VBE12 WITH VOLPI  LOGO
14A TES009 PADDED BACK WITH SHOULDER STRAPS FOR 23VBE16 WITH VOLPI LOGO  -  23VBE16
15 23VBEK8 SELF-TAPPING SCREW KIT 3,5X16
16 WCBLI1A18W 1.0Ah 18W CHARGER
